Acura MDX Factory Error Codes
1 O2A - Oxygen sensor # 1 1 O2A - Oxygen sensor # 1
2 O2B - Oxygen sensor # 2 2 O2B - Oxygen sensor # 2
3 MAP - manifold absolute pressure sensor 3 MAP - manifold absolute pressure sensor
4 CKP - crank position sensor 4 CKP - crank position sensor
5 MAP - manifold absolute pressure sensor 5 MAP - manifold absolute pressure sensor
6 ECT - water temperature sensor 6 ECT - water temperature per sensor
7 TPS - throttle position sensor 7 TPS - throttle position sensor
8 TDC - top dead center sensor 8 TDC - top dead center sensor
9 CYP - cylinder sensor 9 CYP - cylinder position sensor
10 IAT - intake air temperature sensor 10 IAT - intake air temperature sensor
12 EGR - exhaust gas recirculation lift valve 12 exhaust gas recirculation - exhaust gas recirculation system
13 BARO - atmospheric pressure sensor 13 BARO - atmospheric pressure sensor
14 IAC (EACV) - idle air control valve 14 IAC (EACV) - simple air valve
15 Ignition output signal 15 ignition output signal
16 Fuel injectors 16 nozzles
17 VSS - speed sensor 17 VSS - speed sensor
19 Automatic transmission lockup control valve 19 Automatic transmission lockup valve
20 Electrical load detector 20 Electrical load detector
21 VTEC spool solenoid valve 21 VTEC solenoid valve coils
22 VTEC pressure valve 22 VTEC valve
23 Knock sensor 23 Knock sensor
30 Automatic transmission A signal 30 Automatic transmission A signal
31 Automatic transmission B signal 31 Automatic transmission B signal
36 traction control found on JDM ecu's 36 traction found on JDM ECU
41 Primary oxygen sensor heater 41 Primary oxygen sensor heater
43 Fuel supply system 43 Fuel supply system
45 Fuel system too rich or lean 45 Fuel system too rich or lean
48 LAF - lean air fuel sensor 48 LAN - lean air fuel sensor
54 CKF - crank fluctuation sensor 54 cm - crank oscillation sensor
58 TDC sensor # 2 58 TDC sensor # 2
61 Primary oxygen sensor 61 primary oxygen sensors
63 Secondary oxygen sensor 63 Average oxygen sensor
65 Secondary oxygen sensor heater 65 Average oxygen sensor heater
71 random misfire cylinder 1 71 random misfire cylinder 1
72 random misfire cylinder 2 72 random misfire cylinder 2
73 random misfire cylinder 3 73 random misfire cylinder 3
74 random misfire cylinder 4 74 random misfire cylinder 4
P 0010 Variable Valve Timing Control ( VTC ) Oil Control Solenoid Valve Malfunction P 0010 of variable valve timing ( VTC ) The oil control solenoid valve Malfunction
P 0011 Variable Valve Timing Control ( VTC ) System Malfunction P 0011 of variable valve timing ( VTC ) system fault
P 0101 Mass Airflow ( MAF ) Sensor Range / Performance Problem P 0101 mass air flow ( MAF ) sensor range / performance issues
P 0102 Mass Airflow ( MAF ) Sensor Circuit Low Voltage Air Flow P 0102 Mass (MAF) Low Voltage Sensor Circuit
P 0103 Mass Airflow ( MAF ) Sensor Circuit High Voltage Air Flow P 0103 Mass (MAF) High Voltage Sensor Circuit
P 0106 Manifold Absolute Pressure ( MAP ) Sensor Range / Performance Problem P 0106 manifold absolute pressure ( MAP ) sensor range / performance issues
P 0107 Manifold Absolute Pressure ( MAP ) Sensor Circuit Low Voltage P 0107 manifold absolute pressure ( MAP ) sensor circuit low voltage
P 0108 Manifold Absolute Pressure ( MAP ) Sensor Circuit High Voltage P 0108 manifold absolute pressure ( MAP ) sensor circuit high voltage
P 0111 Intake Air Temperature ( IAT ) Sensor Circuit Range / Performance Problem P 0111 intake air temperature ( IAT ) sensor circuit Range / performance issues
P 0112 Intake Air Temperature ( IAT ) Sensor Circuit Low Voltage P 0112 intake air temperature ( IAT ) Supply of low voltage circuit
P 0113 Intake Air Temperature ( IAT ) Sensor Circuit High Voltage P 0113 intake air temperature ( IAT ) sensor high voltage circuit
P 0116 Engine Coolant Temperature ( ECT ) Sensor Circuit Range / Performance Problem P 0116 Engine Coolant Temperature ( ECT ) sensor circuit Range / performance issues
P 0117 Engine Coolant Temperature ( ECT ) Sensor Circuit Low Input P 0117 Engine Coolant Temperature ( ECT ) sensor circuit low input
P 0118 Engine Coolant Temperature ( ECT ) Sensor Circuit High Input P 0118 Engine Coolant Temperature ( ECT ) sensor circuit high input
P 0122 Throttle Position ( TP ) Sensor Circuit Low Input P 0122 throttle position ( TP ) chain low input sensor
P 0123 Throttle Position ( TP ) Sensor Circuit High Input P 0123 throttle position ( TP ) sensor circuit high input
P 0125 Engine Coolant Temperature ( ECT ) Sensor Slow Response P 0125 engine coolant temperature ( ECT ) sensor slow response
P 0128 Cooling System Malfunction P 0128 Cooling system malfunction
P 0131 Primary Heated Oxygen Sensor ( Primary HO 2 S ) ( Sensor 1) Circuit Low Voltage Initial P 0131 heated oxygen sensor (main HO 2 S ) (Sensor 1) Low voltage circuit
P 0132 Primary Heated Oxygen Sensor ( Primary HO 2 S ) ( Sensor 1) Circuit High Voltage Primary P 0132 Heated Oxygen Sensor (Main HO 2 S ) (Sensor 1) High Voltage Circuit
P 0133 Rear Air / Fuel Ratio ( A / F ) Sensor ( Bank 1, Sensor 1) Circuit Slow Response P 0133 Rear combustible mixture ( A / F ) Sensor (Bank 1, Sensor 1) Circuit slow reaction
P0134 Air / Fuel Ratio (A / F) Sensor (Sensor 1) No Activity Detected P0134 combustible mixture (A / F) sensor (Sensor 1) No activity Detected
P0135 Primary Heated Oxygen Sensor (Primary HO2S) (Sensor 1) Heater Circuit Malfunction Primary P0135 Heated Oxygen Sensor (Main HO2S) (Sensor 1) Heater Circuit Malfunction
P0137 Secondary Heated Oxygen Sensor (Secondary HO2S) Circuit Low Voltage Medium P0137 Heated Oxygen Sensor (Medium HO2S) Low Voltage Circuit
P0138 Secondary Heated Oxygen Sensor (Secondary HO2S) Circuit High Voltage Medium P0138 Heated Oxygen Sensor (Medium HO2S) High Voltage Circuit
P0139 Secondary Heated Oxygen Sensor (Secondary HO2S) Slow Response Medium P0139 Heated Oxygen Sensor (Medium HO2S) Slow Reaction
P0141 Secondary Heated Oxygen Sensor (Secondary HO2S) (Sensor 2) Heater Circuit Malfunction Average P0141 Heated Oxygen Sensor (Middle HO2S) (Sensor 2) Heater Circuit Malfunction
P0143 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) Circuit Low Voltage P0143 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) Low Voltage Circuit
P0144 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) Circuit High Voltage P0144 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) High Voltage Circuit
P0145 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) Circuit Slow Response P0145 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) Circuit Slow Reaction
P0147 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) Heater Circuit Malfunction P0147 Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) Heater Circuit Malfunction
P0153 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) Circuit Slow Response P0153 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) Circuit Slow Reaction
P0154 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) Heater System Malfunction P0154 Fuel Mixture Front (A / F) Sensor (Bank 2, Sensor 1) Heating system malfunction
P0155 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) Heater Circuit Malfunction P0155 Fuel Mixture Front (A / F) Sensor (Bank 2, Sensor 1) Heater Circuit Malfunction
P0157 Front Secondary Heated Oxygen Sensor (Secondary HO2S) (Bank 2, Sensor 2) P0157 Front Medium Heated Oxygen Sensor (Middle HO2S) (Bank 2, Sensor 2)
Circuit Low Voltage Low Voltage Circuit
P 0158 Front Secondary Heated Oxygen Sensor ( Secondary HO 2 S ) ( Bank 2, Sensor 2) P 0158 Front Medium Heated Oxygen Sensor (Medium HO 2 S ) (Bank 2, Sensor 2)
Circuit High Voltage High-voltage circuit
P 0159 Front Secondary Heated Oxygen Sensor ( Secondary HO 2 S ) ( Bank 2, Sensor 2) P 0159 Front Medium Heated Oxygen Sensor (Medium HO 2 S ) (Bank 2, Sensor 2)
Circuit Slow Response Chain Slow Response
P 0161 Front Secondary Heated Oxygen Sensor ( Secondary HO 2 S ) ( Bank 2, Sensor 2) P 0161 Front Medium Heated Oxygen Sensor (Medium HO 2 S ) (Bank 2, Sensor 2)
Heater Circuit Malfunction Fault heater circuit
P 0171 Fuel System Too Lean P 0171 Too Lean Fuel System
P 0172 the Fuel the System for Too Rich P 0172 fuel system is too rich
P 0174 Front Bank ( Bank 2) Fuel System Too Lean P 0174 Front Bank (Bank 2) Fuel System Too Lean
P 0175 Front Bank ( Bank 2) Fuel System Too Rich P 0175 Front Bank (Bank 2) Fuel System Too rich
P 0191 Fuel Pressure Sensor Range / Performance Problem P 0191 fuel pressure sensor range / performance issues
P 0192 Fuel Pressure Sensor Circuit Low Voltage P 0192 fuel pressure sensor circuit low voltage
P 0193 Fuel Pressure Sensor Circuit High Voltage P 0193 fuel pressure sensor high voltage circuit
P0196 EOT Sensor / Range Performance Problem P0196 SRV Sensor
P0197 EOT Sensor Circuit Low Voltage P0197 SRV Low Voltage Sensor Circuit
P0198 EOT Sensor Circuit High Voltage P0198 SRV High Voltage Sensor Circuit
P0222 Throttle Position (TP) Sensor 2 Circuit Low Voltage P0222 Throttle Position (TP) Sensor 2 Circuit Low Voltage
P0223 Throttle Position (TP) Sensor 2 Circuit High Voltage P0223 Throttle Position (TP) Sensor 2 High Voltage Circuit
P0300 Random Misfire P0300 Random Misfire
P0301 No. 1 Cylinder Misfire P0301 No. 1 Misfire Cylinder
P0302 No. 2 Cylinder Misfire P0302 No. 2 Misfire Cylinder
P0303 No. 3 Cylinder Misfire P0303 No. 3 Misfire Cylinder
P0304 No. 4 Cylinder Misfire P0304 No. 4 Misfire Cylinder
P0305 No. 5 Cylinder Misfire P0305 No. 5 Cylinders Misfire
P0306 No. 6 Cylinder Misfire P0306 No. 6 Misfire Cylinders
P0325 Knock Sensor Circuit Malfunction P0325 Knock Sensor Circuit Malfunction
P0335 Crankshaft Position (CKP) Sensor Circuit No Signal P0335 Crankshaft Position (CKP) Sensor Circuit No Signal
P0336 P0336
P0339 P0339
Crankshaft Position (CKP) Sensor Circuit Intermittent Interruption Crankshaft Position (CKP) Sensor Circuit Short Term Interruption
P0340 Camshaft Position (CMP) Sensor No Signal Camshaft Position P0340 (CMP) Sensor No Signal
P0341 Camshaft Position (CMP) Sensor A Intermittent Interruption Camshaft Position P0341 (CMP) Short-term interruption sensor
P0341 Variable Valve Timing Control (VTC) Phase Gap P0341 Variable Valve Timing (VTC) Gap Stage
P0344 Camshaft Position (CMP) Sensor Intermittent Interruption Camshaft Position P0344 (CMP) Short-term interruption sensor
P0365 Camshaft Position (CMP) Sensor B No Signal Camshaft Position P0365 (CMP) Sensor B No Signal
P0366 P0366
P0369 P0369
Camshaft Position (CMP) Sensor B Intermittent Interruption Camshaft Position (CMP) Sensor B Short-term interruption
P0385 Crankshaft Position (CKP) Sensor B No Signal Crankshaft Position (CKP) Sensor B No Signal
P0389 Crankshaft Position (CKP) Sensor B Intermittent Interruption Position P0389 Crankshaft (CKP) Sensor B Short term interruption
P0401 Exhaust Gas Recirculation (EGR) Insufficient Flow P0401 Exhaust Gas Recirculation (EGR) Insufficient Flow
P0404 Exhaust Gas Recirculation (EGR) Control Circuit Range / Performance Problem P0404 Exhaust Gas Recirculation (EGR) Board Control Range / Performance Problems
P0406 Exhaust Gas Recirculation (EGR) Valve Position Sensor Circuit High Voltage P0406 Exhaust Gas Recirculation (EGR) Valve Position Circuit High Voltage Sensor
P0410 Air Pump Circuit Malfunction P0410 Air Pump Circuit Malfunction
P0411 Secondary Air Injection System Incorrect Flow P0411 Secondary Air Injection System Incorrect Flow
P0420 Catalyst System Efficiency Below Threshold P0420 Catalyst System Efficiency Below Threshold
P0430 Front Bank Catalyst System Efficiency Below Threshold (Bank 2) P0430 Front Bank Catalyst System Efficiency Below Threshold (Bank 2)
P0441 Evaporative Emission (EVAP) Control System Incorrect Purge Flow P0441 Evaporative Emissions (Evaporations) Control System Incorrect Cleaning Flow
P0442 Evaporative Emission (EVAP) System Small Leak Detected P0442 Evaporative Emissions (Evaporations) Small Leak System Defined
P0443 Evaporative Emission (EVAP) Canister Purge Valve Circuit Malfunction P0443 Evaporative Emissions (Evaporations) Canister Cleaning Valve Circuit Malfunction
P0451 Fuel Tank Pressure (FTP) Sensor Range / Performance Problem P0451 Fuel Tank Pressure (FTP) Sensor Range / Performance Problems
P0452 Fuel Tank Pressure (FTP) Sensor Circuit Low Voltage Pressure P0452 Fuel Tank (FTP) Low Voltage Sensor Circuit
P0453 Fuel Tank Pressure (FTP) Sensor Circuit High Voltage Pressure P0453 Fuel Tank (FTP) High Voltage Sensor Circuit
P0456 Evaporative Emission (EVAP) System Very Small Leak Detected P0456 Evaporative Emissions (Evaporations) System with very low leakage Defined
P0457 Evaporative Emission (EVAP) System Leak Detected Fuel Fill Cap Loose / Off P0457 Evaporative Emissions (Evaporation) Fuel Leak System Defined Fill Cap Loose / Off
P0461 Fuel Gauge Sending Unit Range / Performance Problem P0461 Fuel Level Sending Unit Range / Performance Problem
P0462 Fuel Gauge Sending Unit Circuit Low Voltage P0462 Gauge Fuel Sending Unit Low Voltage Circuit
P0463 Fuel Gauge Sending Unit Circuit High Voltage P0463 Gauge Fuel Sending Unit High Voltage Circuit
P0496 Evaporative Emission (EVAP) System High Purge Flow P0496 Evaporative Emissions (Evaporations) High Purge Flow System
P0497 Evaporative Emission (EVAP) System Low Purge Flow P0497 Evaporative Emission (Evaporative) Low Flow Cleaning System
P0498 Evaporative Emission (EVAP) Canister Vent Shut Valve Control Circuit Low Voltage P0498 Evaporative Emission (Evaporate) Canister Vent Jester Circuit Low Voltage Control Valve
P0499 Evaporative Emission (EVAP) Canister Vent Shut Valve Control Circuit High Voltage P0499 Evaporative Emission (Evaporate) Canister Vent Jester Control Valve Circuit High Voltage
P0500 Vehicle Speed Sensor (VSS) Circuit Malfunction P0500 Vehicle Speed Sensor (VSS) Circuit Malfunction
P0501 Vehicle Speed Sensor (VSS) Range / Peformance Problem P0501 Vehicle Speed Sensor (VSS) Range / Problem Self Freedom
P0505 Idle Control System Malfunction Idle P0505 Control system malfunction
P0506 Idle Control System RPM Lower Than Expected P0506 Control RPM lower than expected
P0507 Idle Control System RPM Higher Than Expected P0507 RPM of control system higher than expected
P0511 Idle Air Control (IAC) Valve Circuit Malfunction P0511 Standby Air Control (IAC) Valve Circuit Malfunction
P0521 EOP Sensor Range / Performance Problem P0521 EOP Sensor Range / Performance Problem
P0522 EOP Sensor Circuit Low Voltage P0522 EOP Circuit Low Voltage Sensor
P0523 EOP Sensor Circuit High Voltage P0523 EOP Circuit High Voltage Sensor
P0560 ECM Back-up Circuit Low Voltage P0560 ECM redundant low voltage circuit
P0563 Engine Control Module (ECM) / Powertrain Control Module (PCM) Power Source Circuit P0563 Engine Control Module (ECM) / Powertrain Control Module (PCM) Power supply circuit
Unexpected Voltage Unexpected Voltage
P0600 Multiplex Control System Troubleshooting P0600 Multiplex Control System Troubleshooting
P0603 ECM / PCM Internal Control Module Keep Alive Memory (KAM) Error P0603 ECM / PCM Internal Control Module Keep Alive Memory (KAM) Error
P0606 ECM / PCM Processor Malfunction P0606 ECM / PCM Processor Fault
P0661 Intake Manifold Runner Control (IMRC) Valve Position Sensor Circuit Low Voltage P0661 Intake Manifold Runner Control (Hellish Mail) Valve Low Voltage Sensor Circuit Position
P0662 Intake Manifold Runner Control (IMRC) Valve Position Sensor Circuit High Voltage P0662 Intake Manifold Runner Control (Hellish Mail) Valve High Voltage Sensor Circuit Position
P0685 ECM / PCM Power Relay Control Circuit Malfunction P0685 ECM / PCM Relay Control Circuit Malfunction
P 0700 the Automatic the Transmission the Control the System P 0700 automatic transmission system management
P0705 Short in Transmission Range Switch Circuit (Multiple Shift-position Input) P0705 Short in Transmission Range Switch Circuit (Multiple Shift-Position Input)
P0706 Open in Transmission Range Switch Circuit P0706 Open in Transmission Range Switch Range
P0710 P0710
P0711 P0711
Problem in ATF Temperature Sensor Circuit Problem in ATF Temperature Sensor Circuit
P0712 Short in ATF Temperature Sensor Circuit Short P0712 in ATF temperature sensor circuit
P0713 Open in ATF Temperature Sensor Circuit P0713 Open in ATF temperature sensor circuit
P0715 P0715
P0716 P0716
Problem in Mainshaft Speed Sensor Circuit Problem in Shaft Speed Sensor Circuit
P0717 Problem in Mainshaft Speed Sensor Circuit (No Signal Input) P0717 Problem in the sensor circuit by the shaft Speed (without input signal)
P0718 Mainshaft Speed Sensor Intermittent Failure P0718 Shaft Speed Sensor Intermittent Failure
P0720 Countershaft Speed Sensor Circuit Malfunction P0720 Shaft Speed Sensor Circuit Malfunction
P0720 P0720
P0721 P0721
Problem in Countershaft Speed Sensor Circuit Problem in Shaft Speed Sensor Circuit
P0722 Problem in Countershaft Speed Sensor Circuit (No Signal Input) P0722 Problem in the circuit Speed sensor shaft (no input signal)
P0723 Countershaft Speed Sensor Intermittent Failure P0723 Shaft Speed Sensor Intermittent Failure
P0725 Engine Speed Input Circuit Malfunction P0725 Engine Speed Input Circuit Malfunction
P0730 Problem in Shift Control System P0730 Problem in Shift Control System
P0731 Problem in 1st Clutch and 1st Clutch Hydraulic Circuit P0731 Problem in the first clutch and first hydraulic circuit
P0732 Problem in 2nd Clutch and 2nd Clutch Hydraulic Circuit P0732 Problem in the second clutch and second clutch hydraulic circuit
P0733 Problem in 3rd Clutch and 3rd Clutch Hydraulic Circuit P0733 Problem in the third clutch and third hydraulic circuit
P0734 Problem in 4th Clutch and 4th Clutch Hydraulic Clutch P0734 Problem in the 4th and 4th clutch Hydraulic clutch
P0735 Problem in 5th Clutch and 5th Clutch Hydraulic Circuit P0735 Problem in fifth clutch and fifth clutch hydraulic circuit
P0740 Problem in Lock-up Control System P0740 Problem in Lock-up control system
P0741 Torque Converter Clutch Hydraulic Clutch Stuck OFF P0741 Torque Converter Clutch Clutch Hydraulic Stuck OFF
P0743 Problem in Torque Converter Clutch Solenoid Valve Circuit P0743 Problem in torque converter clutch solenoid valve circuit
P0745 Problem in Hydraulic Control System of A / T Clutch Pressure Control Solenoid Valve A Circuit P0745 Problem in A / T Hydraulic Control System Clutch Pressure Control Solenoid Valve Circuit
P0746 A / T Clutch Pressure Control Solenoid Valve A Stuck OFF P0746 / T Clutch Pressure Control Solenoid Valve Stuck OFF
P0747 A / T Clutch Pressure Control Solenoid Valve A Stuck ON P0747 / T Clutch Pressure Control Solenoid Valve Stuck On
P0748 Problem in A / T Clutch Pressure Control Solenoid Valve A Circuit P0748 Problem in / T Clutch Pressure Control Solenoid Valve Circuit
P0750 Problem in Hydraulic Control System of Shift Solenoid Valve A Circuit P0750 Problem in Hydraulic Control System Shift Solenoid Valve Circuit
P0751 Shift Solenoid Valve A Stuck OFF P0751 Shift Solenoid Valve Stuck OFF
P0752 Shift Solenoid Valve A Stuck ON P0752 Shift Solenoid Valve Stuck On
P0753 Problem in Shift Solenoid Valve A Circuit P0753 Problem in Shift Solenoid Valve Circuit
P0756 Shift Solenoid Valve B Stuck OFF P0756 Shift Solenoid Valve B Stuck OFF
P0757 Shift Solenoid Valve B Stuck ON P0757 Shift Solenoid Valve B Stuck On
P0758 Problem in Shift Solenoid Valve B Circuit P0758 Problem in Shift Solenoid Valve B Circuit
P0761 Shift Solenoid Valve C Stuck OFF P0761 Shift Solenoid Valve C Stuck OFF
P0762 Shift Solenoid Valve C Stuck ON P0762 Shift Solenoid Valve C Stuck On
P0763 Problem in Shift Solenoid Valve C Circuit P0763 Problem in Shift Solenoid Valve Circuit C
P0771 Shift Solenoid Valve E Stuck OFF P0771 Shift Solenoid Valve E Stuck OFF
P0773 Problem in Shift Solenoid Valve E Circuit P0773 Problem in Shift Solenoid Valve E Circuit
P0775 Problem in the Hydraulic Control System of A / T Clutch Pressure Control Solenoid Valve B P0775 Problem in the hydraulic control system A / T clutch pressure control solenoid valve B
Circuit Chain
P0776 A / T Clutch Pressure Control Solenoid Valve B Stuck OFF P0776 / T Clutch Pressure Control Solenoid Valve B Stuck OFF
P0777 A / T Clutch Pressure Control Solenoid Valve B Stuck ON P0777 / T Clutch Pressure Control Solenoid Valve B Stuck On
P0778 Problem in A / T Clutch Pressure Control Solenoid Valve B Circuit P0778 Problem in / T Clutch Pressure Control Solenoid Valve B Circuit
P0780 Problem in Shift Control System P0780 Problem in Shift Control System
P0795 Problem in Hydraulic Control System of A / T Clutch Pressure Control Solenoid Valve C Circuit P0795 Problem in Hydraulic Control System A / T Clutch Pressure Control Solenoid valve circuit C
P0796 A / T Clutch Pressure Control Solenoid Valve C Stuck OFF P0796 / T Clutch Pressure Control Solenoid Valve C Stuck OFF
P0797 A / T Clutch Pressure Control Solenoid Valve C Stuck ON P0797 / T Clutch Pressure Control Solenoid Valve C Stuck On
P0798 Problem in A / T Clutch Pressure Control Solenoid Valve C Ciruit P0798 Problem in / T Clutch Pressure Control Solenoid Valve C Ciruit
P0812 Open in Transmission Range Switch ATP RVS Switch Circuit P0812 Open in Transmission RVS Switch Range ATP Switch Circuit
P0842 Short in 2nd Clutch Transmission Fluid Pressure Switch Clutch, or 2nd Clutch Transmission P0842 Short Second Gear Coupling Fluid Pressure Clutch Switch, or Second Gear Coupling
Fluid Pressure Switch (Clutch) Stuck ON Fluid Pressure Switch (Clutch) Stuck On
P0843 Open in 2nd Clutch Transmission Fluid Pressure Switch Circuit, or 2nd Clutch Transmission Open in P0843 Second Gear Coupling Fluid Pressure Switch Circuit, or Second Gear Coupling
Fluid Pressure Switch Stuck OFF Fluid Pressure Switch Stuck OFF
P0845 Problem in 3rd Clutch Pressure Switch Circuit P0845 Problem in Third Clutch Pressure Switch Circuit
P0847 Short in 3rd Clutch Transmission Fluid Pressure Switch Circuit, or 3rd Clutch Transmission Short P0847 in Third Clutch Fluid Pressure Switch Circuit, or Third Clutch
Fluid Pressure Switch Stuck ON Fluid Pressure Switch Stuck On
P0848 Open in 3rd Clutch Transmission Fluid Pressure Switch Circuit, or 3rd Clutch Transmission P0848 Open in Third Clutch Fluid Pressure Switch Circuit, or Third Clutch
Fluid Pressure Switch Stuck OFF Fluid Pressure Switch Stuck OFF
P0872 Short in 4th Clutch Transmission Fluid Pressure Switch Circuit, or 4th Clutch Transmission Short P0872 in 4 clutch Fluid Pressure Switch Circuit, or 4 clutch
Fluid Pressure Switch Stuck ON Fluid Pressure Switch Stuck On
P0873 Open in 4th Clutch Transmission Fluid Pressure Switch Circuit, or 4th Clutch Transmission P0873 open in 4th clutch Fluid Pressure Switch Circuit, or 4 clutch
Fluid Pressure Switch Stuck OFF Fluid Pressure Switch Stuck OFF
P0962 Problem in A / T Clutch Pressure Control Solenoid Valve A Circuit P0962 Problem in / T Clutch Pressure Control Solenoid Valve Circuit
P0963 Problem in A / T Clutch Pressure Control Solenoid Valve A P0963 Problem in / T Clutch Pressure Control Solenoid Valve
P0966 Problem in A / T Clutch Pressure Control Solenoid Valve B Circuit P0966 Problem in / T Clutch Pressure Control Solenoid Valve B Circuit
P0967 Problem in A / T Clutch Pressure Control Solenoid Valve B P0967 Problem in / T Clutch Pressure Control Solenoid Valve B
P0970 Problem in A / T Clutch Pressure Control Solenoid Valve C Circuit P0970 Problem in / T Clutch Pressure Control Solenoid Valve Circuit C
P0971 Problem in A / T Clutch Pressure Control Solenoid Valve C P0971 Problem in / T Clutch Pressure Control Solenoid Valve C
P0973 Short in Shift Solenoid Valve A Circuit Short P0973 in Shift Solenoid Valve Circuit
P0974 Open in Shift Solenoid Valve A Circuit P0974 Open in Shift Solenoid Valve Circuit
P0976 Short in Shift Solenoid Valve B Circuit P0976 Short Shift Solenoid Valve B Circuit
P0977 Open in Shift Solenoid Valve B Circuit P0977 Open in Shift Solenoid Valve B Circuit
P0979 Short in Shift Solenoid Valve C Circuit Short P0979 in Shift Solenoid Valve Circuit C
P0980 Open in Shift Solenoid Valve C Circuit P0980 Open in Shift Solenoid Valve C Circuit
P0982 Short in Shift Solenoid Valve D Circuit P0982 Short in Shift Solenoid Valve D Circuit
P0983 Open in Shift Solenoid Valve D Circuit P0983 Open in Shift Solenoid Valve D Circuit
P0985 Short in Shift Solenoid Valve E Circuit P0985 Short in Shift Solenoid Valve E Circuit
P0986 Open in Shift Solenoid Valve E Circuit P0986 Open in Shift Solenoid Valve E Circuit
P1020 Valve Pause System Stuck Off P1020 Valve System Pause Stuck Off
P1021 Valve Pause System Stuck On P1021 Valve System Pause Stuck On
P1025 Valve Pause System Sticking Off P1025 Valve System Pause Paste Off
P1026 Valve Pause System Sticking On P1026 Valve System Pause Stickers
P1077 Intake Manifold Runner Control (IMRC) System Malfunction (Low rpm) P1077 Intake Manifold Runner Control (Infernal mail) System malfunction (low / min)
P1078 Intake Mainfold Runner Control (IMRC) System Malfunction (High rpm) P1078 Receive manifold Runner control (Infernal mail) System malfunction (High rpm)
P1106 Barometric Pressure (BARO) Sensor Circuit Range / Performance Problem Atmospheric Pressure P1106 (BARO) Sensor Circuit Range / Performance Problems
P1107 Barometric Pressure (BARO) Sensor Circuit Low Voltage Atmospheric Pressure P1107 (BARO) Low Voltage Sensor Circuit
P1108 Barometric Pressure (BARO) Sensor Circuit High Voltage Atmospheric Pressure P1108 (BARO) High Voltage Sensor Circuit
P1121 Throttle Position (TP) Sensor Lower Than Expected P1121 Throttle Position (TP) Sensor Lower Than Expected
P1122 Throttle Position (TP) Sensor Higher Than Expected P1122 Throttle Position (TP) Sensor Higher Than Expected
P1128 Manifold Absolute Pressure (MAP) Sensor Circuit Lower Than Expected P1128 manifold absolute pressure (MAP) sensor circuit less than expected
P1129 Manifold Absolute Pressure (MAP) Sensor Circuit Higher Than Expected P1129 manifold absolute pressure (MAP) sensor circuit is higher than expected
P1130 Demand for Changing Both Secondary Heated Oxygen Sensor (Secondary HO2S) P1130 Demand for change as average heated oxygen sensor (average HO2S)
(Sensor 2) and Third Heated Oxygen Sensor (Third HO2S) (Sensor 3) (Sensor 2) and a third heated oxygen sensor (Third HO2S) (sensor 3)
P1149 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Range / Performance Problem P1149 Fuel Mixture (A / F) Sensor (Sensor 1) Range / Performance Problems
P1149 Air / Fuel Ratio Sensor (Sensor 1) Circuit Lean Range P1149 Combustible Sensor (Sensor 1) Circuit Lean Range
P1157 Air / Fuel Ratio (A / F) Sensor (Sensor 1) AFS Line High Voltage P1157 combustible mixture (A / F) sensor (sensor 1) AFS high voltage line
P1157 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Circuit High Voltage P1157 Fuel Mixture (A / F) Sensor (Sensor 1) High Voltage Circuit
P1157 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Range / Performance Problem P1157 combustible mixture (A / F) sensor (Sensor 1) Range / Performance problems
P1158 Air / Fuel Ratio (A / F) Sensor (Sensor 1) AFS- Terminal Low Voltage P1158 combustible mixture (A / F) sensor (sensor 1) AFS-terminals low voltage
P1159 Air / Fuel Ratio (A / F) Sensor (Sensor 1) AFS + Terminal Low Voltage P1159 combustible mixture (A / F) sensor (sensor 1) + AFS low voltage terminals
P1162 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Slow Response P1162 combustible mixture (A / F) sensor (sensor 1) slow reaction
P1163 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Slow Response P1163 combustible mixture (A / F) sensor (sensor 1) slow reaction
P1163 Air / Fuel Ratio Sensor (Sensor 1) Slow Response P1163 combustible mixture sensor (sensor 1) slow reaction
P1164 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Range / Performance Problem P1164 Fuel Mixture (A / F) Sensor (Sensor 1) Range / Performance Problems
P1164 Air / Fuel Ratio (AF) Sensor (Sensor 1) Circuit Range / Performance P1164 Fuel Mixture (AF) Sensor (Sensor 1) Circuit Range / Performance
P1165 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Range / Performance Problem P1165 Fuel Mixture (A / F) Sensor (Sensor 1) Range / Performance Problems
P1165 Air / Fuel Ratio Sensor (Sensor 1) Circuit Range / Performance P1165 Combustible Sensor (Sensor 1) Circuit Range / Performance
P1166 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Heater System Electrical Problem P1166 Combustible mixture (A / F) sensor (Sensor 1) Electrical heating system problems
P1166 Heated Oxgen Sensor Sensor1 (Primary HO2S) Heater Circuit Malfunction P1166 Heated Sensor Oxgen sensor1 (Initial HO2S) Heater Circuit Malfunction
P1167 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Heater System Malfunction P1167 combustible mixture (A / F) sensor (sensor 1) Heating system malfunction
P1167 Heated Oxygen Sensor Sensor1 (Primary LAF HO2S) Heater System Malfunction P1167 Heated Oxygen Sensor sensor1 (Initial LAN HO2S) Heating system malfunction
P1168 Air / Fuel Ratio (A / F) Sensor (Sensor 1) LABEL Low Voltage P1168 combustible mixture (A / F) sensor (sensor 1) LOW LABEL
P1169 Air / Fuel Ratio (A / F) Sensor (Sensor 1) LABEL High Voltage P1169 combustible mixture (A / F) sensor (sensor 1) LABEL
P1182 Fuel Temperature Sensor Circuit Low Voltage P1182 Fuel Temperature Sensor Circuit Low Voltage
P1183 Fuel Temperature Sensor Circuit High Voltage P1183 Fuel Temperature Sensor Circuit High Voltage
P1253 P1253
P1259 P1259
VTEC System Malfunction VTEC system malfunctions
P1297 Electric Load Detector (ELD) Circuit Low Voltage P1297 Electric Load Detector (ELD) Circuit Low Voltage
P1298 Electric Load Detector (ELD) Circuit High Voltage P1298 Electric Load Detector (ELD) Circuit High Voltage
P1300 Random Misfire P1300 Random Misfire
P1324 Knock Sensor Power Source Circuit Low Voltage P1324 Knock Sensor Power Source Circuit Low Voltage
P1336 Engine Speed (RPM) Fluctuation Sensor Intermittent Interruption P1336 Engine Speed (RPM) Sensor Oscillation Short Interruption
P1337 Engine Speed (RPM) Fluctuation Sensor No Signal P1337 Engine Speed (RPM) Sensor Oscillation No Signal
P1355 Front Ignition Coil Power Circuit Malfunction P1355 Front Ignition Coil Malfunction Power Circuit
P1359 Crankshaft Position (CKP) / Top Dead Center (TDC) Sensor Circuit Malfunction Position P1359 Crankshaft (CKP) / Top Dead Center (TDC) Sensor Circuit Malfunction
P1361 Camshaft Position (CMP) Sensor A (Top Dead Center (TDC) Sensor) Intermittent Interruption Camshaft Position P1361 (CMP) Sensor (Top Dead Center (TDC) Sensor) Short-term interruption
P1361 Top Dead Center (TDC) Sensor Intermittent Interruption P1361 Top Dead Center (TDC) Short Term Interrupt Sensor
P1362 Camshaft Position (CMP) Sensor A (Top Dead Center (TDC) Sensor) No Signal P1362 Camshaft Position (CMP) Sensor (Top Dead Center (TDC) Sensor) No signal
P1362 Top Dead Center (TDC) Sensor No Signal P1362 Top Dead Center (TDC) No Sensor Signal
P1366 Camshaft Position (CMP) Sensor B (Top Dead Center (TDC) Sensor) Intermittent Interruption Camshaft Position P1366 (CMP) Sensor B (Top Dead Center (TDC) Sensor) Short-term interruption
P1366 Top Dead Center (TDC) Sensor 2 Intermittent Interruption P1366 Top Dead Center (TDC) Sensor 2 Short Term Interruption
P1367 Camshaft Position (CMP) Sensor B (Top Dead Center (TDC) Sensor) No Signal Camshaft Position P1367 (CMP) Sensor B (Top Dead Center (TDC) Sensor) No signal
P1367 Top Dear Center (TDC) Sensor 2 No Signal P1367 Best Dear Center (TDC) Sensor 2 No Signal
P1381 Cylinder Position (CYP) Sensor Intermittent Interruption P1381 Cylinder Position (CYP) Short-term interruption sensor
P1382 Cylinder Position (CYP) Sensor No Signal P1382 Cylinder Position (CYP) No Sensor Signal
P 1410 Air Pump Malfunction P 1410 Fault air pump
P 1415 Air Pump Electric Current Sensor Circuit Low Voltage P 1415 by air the electric current circuit of the low voltage sensor
P 1416 Air Pump Electric Current Sensor Circuit High Voltage P 1416 by air the electric current circuit of the high voltage sensor
P 1420 Nox Adsorptive Catalyst System Efficiency Below Threshold P 1420 Nox adsorption system efficiency Catalyst below a threshold
P 1438 Motor Drive Module ( MDM ) Overheating Signal Circuit P 1438 Motor Drive module ( MDM ) Overheating signal transmission circuit
P 1438 Motor Drive Module ( MDM ) Overheating P 1438 Motor Drive Module ( MDM ) Overheating
P 1439 Motor Drive Module ( MDM ) Short Circuit Sensor Problem P 1439 Motor Drive module ( MDM ) Short circuit sensor Problem
P 1439 Motor Drive Module ( MDM ) Short Circuit P 1439 Motor Drive Module ( MDM ) against short circuit
P1440 IMA System Problem IMA System P1440 Problem
P1445 Bypass Control Problem P1445 Bypass Control Problem
P1448 P1448
P1449 P1449
Battery Module Overheating
P1449 Battery Cell Overheating P1449 Battery Overheating
P1449 Battery Module Individual Voltage Input Deviation P1449 Battery Module Individual Input Voltage Deviation
P1449 Battery Module Deterioration P1449 Battery Module Deterioration
P1449 Battery Module Deviation P1449 Battery Module Deviation
P1454 Fuel Tank Pressure (FTP) Sensor Range / Performance Problem P1454 Fuel Tank Pressure (FTP) Sensor Range / Performance Problems
P1456 Evaporative Emissions (EVAP) Control System Leakage (Fuel Tank System) P1456 Evaporative Emissions (Evaporation) Leakage Control System (Fuel Tank System)
P1457 Evaporative Emissions (EVAP) Control System Leakage (EVAP Canister System) P1457 Evaporative Emissions (Evaporation) Leakage Control System (Evaporation Container System)
P1459 Evaporative Emission (EVAP) Purge Flow Switch Malfunction P1459 Evaporative Emissions (Evaporations) Purge Flow Switch Malfunction
P1491 Exhaust Gas Recirculation (EGR) Valve Insufficient Lift P1491 Exhaust Gas Recirculation (EGR) Valve Inadequate Lift
P1486 Cooling System Malfunction P1486 Cooling System Malfunction
P1491 Exhaust Gas Recirculation (EGR) Valve Insufficient Lift P1491 Exhaust Gas Recirculation (EGR) Valve Inadequate Lift
P1498 Exhaust Gas Recirculation (EGR) Valve Position Sensor Circuit High Voltage P1498 Exhaust Gas Recirculation (EGR) Valve Position Circuit High Voltage Sensor
P1505 Positive Crankcase Ventilation (PCV) Air Leakage P1505 Positive crankcase ventilation (PCV) air leak
P1508 P1508
P1519 P1519
Idle Air Control Valve (IACV) Circuit Malfunction Idle Air Control Valve (IACV) Circuit Malfunction
P1509 Idle Air Control Valve (IACV) Circuit Failure P1509 Standby Air Control Valve (IACV) Circuit
P1522 Brake Booster Pressure Sensor Circuit Low Voltage Brake Booster P1522 Pressure Sensor Low Circuit
P1523 Brake Booster Pressure Sensor Circuit High Voltage Brake Booster P1523 Pressure Sensor High Voltage Circuit
P1524 Brake Booster Pressure Sensor Range / Performance Problem Brake Booster P1524 Pressure Sensor Range / Performance Problem
P1541 Climate Control Unit Signal Circuit Low Voltage P1541 Climate control group circuit transmission signal low voltage
P1542 Climate Control Unit Signal Circuit High Voltage P1542 Climate control group circuit transmission signal high voltage
P1565 Motor Commutation Signal Problem P1565 Motor Commutation Signal Problem
P1568 Battery Module Individual Voltage Input Problem P1568 battery module individual problem Input voltage
P1568 Battery Module Temperature Signal Circuit Problem P1568 Battery Module Temperature Signal Circuit Problem
P1568 Battery Cell Temperature Signal Circuit Problem P1568 Battery Temperature Signal Circuit Problem
P1572 Motor Drive Module (MDM) Temperature Signal Circuit Low Input P1572 Motor Drive Module (MDM) Circuit Low input signal temperature
P1572 Motor Drive Module (MDM) Temperature Signal Circuit High Input P1572 Motor Drive Module (MDM) signal circuit Temperature high input
P1576 Motor Drive Module (MDM) Voltge Signal Circuit Low Input P1576 Motor Drive Module (MDM) Circuit Voltge Low Input Signal
P1577 High Voltage Detection Signal Circuit Problem P1577 High Voltage Detection Signal Circuit Problem Detection
P1580 Battery Current Circuit Problem P1580 Battery Current Circuit Problem
P1581 Motor Power Inverter (MPI) Module Current Signal Circuit Low Input P1581 Motor Power Inverter (MPI) Module Current Signal Low Input
P1581 Motor Power Inverter (MPI) Module Current Signal Circuit High Input P1581 Motor Power Inverter (MPI) Current Signal Module High Input
P1581 Motor Power Inverter (MPI) Module Current Signal Circuit Problem P1581 Motor Power Inverter (MPI) Module Current Problems Signal Circuit
P1582 Motor Current U Phase Signal Circuit Low Input P1582 Current U Phase Signal Circuit Low Input
P1582 Motor Current U Phase Signal Circuit High Input P1582 Phase current signal U circuit high input
P1583 Motor Current V Phase Signal Circuit Low Input P1583 Motor Current V Phase Signal Circuit Low Input
P1583 Motor Current V Phase Signal Circuit High Input P1583 Motor current V phase signal circuit high input
P1584 Motor Current W Phase Signal Circuit Low Input P1584 Current W Phase Signal Circuit Low Input
P1584 Motor Current W Phase Signal Circuit High Input P1584 Current W Phase Signal Circuit High Input
P1585 Motor Current Signal Circuit Problem P1585 Problem current signal circuit
P1586 Motor Power Inverter (MPI) Module Current Signal / Battery Current Signal Circuit Problem P1586 Motor Power Inverter (MPI) Current Signal / Battery Module Current Problems Signal Circuit
P1607 Engine Control Module (ECM) / Powertrain Control Module (PCM) Internal Circuit Malfunction P1607 Engine Control Module (ECM) / Powertrain Control Module (PCM) Internal circuit failure
P1630 Transmission Control Module P1630 Transmission Control Module
P1635 Battery Condition Monitor (BCM) Module Proble Battery Status P1635 Monitor (BCM) Module Proble
P1639 MOTB Signal Circuit Malfunction MOTB P1639 Signal Circuit Malfunction
P1640 ACTTRQ Motor Torque Signal Circuit Low Input P1640 ACTTRQ torque low signal input circuit
P1641 ACTTRQ Motor Torque Signal Circuit High Input P1641 ACTTRQ torque signal transmission circuit high input
P1642 QBATT Battery Signal Circuit Low Input P1642 QBATT Battery Signal Circuit Low Input
P1643 QBATT Battery Signal Circuit High Input P1643 QBATT Battery Signal Circuit High Input
P1644 MOTFSA Signal Malfunction P1644 MOTFSA Signal Failure
P1645 MOTFSB Signal Malfunction P1645 MOTFSB Signal Failure
P1646 MOTSTB Signal Malfunction P1646 MOTSTB Signal Failure
P1647 Power Command Signal Circuit Low Input P1647 Power circuit low input command signal
P1647 Power Command Signal Circuit High Input P1647 Power Command Signal Circuit High Input
P1647 Engine Torque Signal Circuit Low Input P1647 Engine Torque Signal Circuit Low Input
P1647 Engine Torque Signal Circuit High Input P1647 Engine Torque Signal Circuit High Input
P1647 Mode Signal Circuit 1 Low Input P1647 Mode Signal Circuit 1 Low Input
P1647 Mode Signal Circuit 1 High Input P1647 Mode Signal Circuit 1 High Input
P1647 Mode Signal Circuit 2 Problem P1647 Mode Signal Circuit 2 Problem
P1647 Engine Speed Signal Circuit Problem P1647 Engine Speed Signal Circuit Problem
P1648 Battery Condition Monitor (BCM) Module Communication Signal Circuit Problem Battery Status P1648 Monitor (BCM) Module Communication Signal Circuit Problem
P1648 Motor Control Module (MCM) Communication Signal Circuit Problem P1648 Motor Control Module (MCM) Message Signal Transmission Circuit Problem
P1655 CVT-FI TMA / TMB Signal Line Failure P1655 CVT-TMA-FI / TMB Signal Line Failure
P1656 Problem in PCM-toVTM-4 Control Unit Communications Circuit P1656 Problem in PCM-toVTM-4 Control Unit Communications Circuit
P1660 A / T-FI Data Line Failure / TCM - ECM Halt P1660 / T-FI Data Line Failure / TCM - ECM Stop
P1676 P1676
P1678 P1678
FPTDR Signal Line Failure FPTDR Signal Line Failure
P1679 RSCD Signal Circuit Malfunction P1679 RSCD Signal Circuit Malfunction
P1681 A / T FI Signal A Cicuit Low Voltage P1681 / T FI Signal A Cicuit Low Voltage
P1682 A / T FI Signal A Circuit High Voltage P1682 / T FI Signal High Circuit
P1683 Throttle Valve Default Position Spring Performance Problem P1683 Throttle Position default Spring performance problems
P 1684 Throttle Valve's Return Spring the Performance Problem P 1684 Throttle Return Spring performance problems
P 1686 A / T FI Signal B Circuit Low Voltage P 1686 / T FI chain signal B low voltage
P 1687 A / T FI Signal B Circuit High Voltage P 1687 / T FI Signal B Circuit High Voltage
P1705 Short in Transmission Range Switch Circuit (More than one range position position is on at the Short P1705 in Transmission Range Switch circuit (more than 1 lap position, at
same time ) same time)
P1706 Open in Transmission Range Switch Circuit P1706 Open in Transmission Range Switch Range
P1709 Problem Transmission Gear Selection Switch Circuit P1709 Problem Transmission Gear Selection Circuit
P1730 Problem in Shift Control System: P1730 Problem in Shift Control System:
Shift Solenoid Valve A and D Stuck OFF Shift Solenoid Valve and D OFF Stuck
Shift Solenoid Valve B Stuck ON Shift Solenoid Valve B Stuck On
Shift Valves A, B, and D Stuck Shift Valves A, B, D and Stuck
P1731 Problem in Shift Control System: P1731 Problem in Shift Control System:
Shift Solenoid Valve E Stuck ON Shift Solenoid Valve E Stuck On
Shift Valve E Stuck Shift Valve E Stuck
A / T Clutch Pressure Control Solenoid Valve A Stuck OFF / T Clutch Pressure Control Solenoid Valve Stuck OFF
P1732 Problem in Shift Control System: P1732 Problem in Shift Control System:
Shift Solenoid Valve B and C Stuck ON Shift Solenoid Valve B and C Stuck On
Shift Valves B and C Stuck Shift Valves B and C Stuck
P1733 Problem in Shift Control System: P1733 Problem in Shift Control System:
Shift Solenoid Valve D Stuck ON Shift Solenoid Valve D Stuck On
Shift Valve D Stuck Shift Valve D Stuck
A / T Clutch Pressure Control Solenoid Valve C Stuck OFF / T Clutch Pressure Control Solenoid Valve C Stuck OFF
P1734 Problem in Shift Control System: P1734 Problem in Shift Control System:
Shift Solenoid Valves B and C Stuck ON Shift Solenoid Valves B and C Stuck On
Shift Valves B and C Stuck Shift Valves B and C Stuck
P1738 Problem in 2nd Clutch Pressure Switch Circuit P1738 Problem in the second clutch circuit of the pressure switch
P1739 Problem in 3rd Clutch Pressure Switch Circuit P1739 Problem in Third Clutch Pressure Switch Circuit
P1740 Problem in 4th Clutch Pressure Switch Circuit P1740 Problem in 4th Clutch Pressure Switch Circuit
P1750 Mechanical Problem in Hydraulic Control System of A / T Clutch Pressure Control Solenoid P1750 Mechanical Failure in A / T Hydraulic Clutch Pressure Control Solenoid
Valve Assemblies A and B, or Problem in the Hydraulic Control System Valves and B, or Problem in the hydraulic control system
P1751 Mechanical Problem in Hydraulic Control System of Shift Solenoid Valve B and A / T Clutch P1751 Mechanical Problem in Hydraulic Control System Shift Solenoid Valve B and A / T Clutch
Pressure Control Solenoid Valves A and B, or Problem in the Hydraulic Control System Pressure control Solenoid valves and B, or problems in the hydraulic control system
P1753 Problem in Torque Converter Clutch Solenoid Valve Circuit P1753 Problem in torque converter clutch solenoid valve circuit
P1751 P1751
P1768 P1768
Problem in Torque Converter Clutch Solenoid Valve B Circuit Problem in torque converter clutch solenoid valve B circuit
P1773 Problem in A / T Clutch Pressure Control Solenoid Valve B Circuit P1773 Problem in / T Clutch Pressure Control Solenoid Valve B Circuit
P1790 Throttle Position (TP) Sensor Circuit Malfunction P1790 Throttle Position (TP) Sensor Circuit Malfunction
P1791 Vehicle Speed Sensor (VSS) Range / Performance Problem P1791 Vehicle Speed Sensor (VSS) Range / Performance Problem
P1792 Problem in Engine Coolant Temperature (ECT) Sensor Circuit P1792 Problem in Engine Coolant Temperature (ECT) Sensor Circuit
P1793 Manifold Absolute Pressure Sensor Circuit P1793 manifold absolute pressure sensor circuit
P1870 Problem in CVT Speed Change Control Valve Assembly Circuit P1870 Problem in CVT Speed of control circuit change Valve mounting
P1873 Problem in CVT Pulley Pressure Control Valve Assembly Circuit P1873 Problem in CVT Pulse Pressure Control Circuit Valve Installation
P1879 Problem in CVT Start Clutch Pressure Control Valve Assembly Circuit P1879 Problem in CVT Start Pressure Control Circuit Valve Installation
P1882 Problem in Inhibitor Solenoid Circuit P1882 Problem in the electromagnetic circuit of the inhibitor
P1884 Secondary Gear Speed Sensor 2 Circuit Malfunction Medium P1884 Gear 2 Speed Sensor Circuit Malfunction
P1885 CVT Drive Pulley Speed Sensor Circuit P1885 CVT Bullet Drive Speed Sensor Circuit
P1886 CVT Driven Pulley Speed Sensor Circuit P1886 CVT driven pulley speed sensor circuit
P1888 CVT Speed Sensor CVT P1888 Speed Sensor
P1889 Problem in CVT Speed Sensor 2 Circuit P1889 Problem in CVT Speed Sensor 2 Circuit
P1890 Shift Control System P1890 Shift Control System
P1891 Problem in Start Clutch System P1891 Problem Starting Clutch System
P1894 CVT Speed Change Control Valve Circuit P1894 CVT Speed Change Valve Circuit
P1895 CVT Pulley Pressure Control Valve Circuit P1895 CVT Bullet Valve for Regulating Circuit
P2101 Throttle Actuator System Malfunction Throttle Actuator P2101 System Fault
P2108 Throttle Actuator Control Module Problem Throttle Actuator P2108 Problem Control Module
P2118 Throttle Actuator Current Range / Performance Problem Throttle Actuator P2118 Current Range / Performance Problems
P2122 Accelerator Pedal Position (APP) Sensor 1 (Throttle Position Sensor D) Circuit Low Voltage P2122 Accelerator Pedal (APP) Sensor 1 (Throttle Position Sensor D) Low Voltage Circuit
P2123 Accelerator Pedal Position (APP) Sensor 1 (Throttle Position Sensor D) Circuit High Voltage P2123 Accelerator Pedal (APP) Sensor 1 (Throttle Position Sensor D) High Voltage Circuit
P2127 Accelerator Pedal Position (APP) Sensor 2 (Throttle Position Sensor E) Circuit Low Voltage P2127 Accelerator Pedal (APP) Sensor 2 (Throttle Position Sensor E) Low Voltage Circuit
P2128 Accelerator Pedal Position (APP) Sensor 2 (Throttle Position Sensor E) Circuit High Voltage P2128 Accelerator Pedal (APP) Sensor 2 (Throttle Position Sensor E) High Voltage Circuit
P2135 Throttle Position (TP) Sensor 1/2 Incorrect Voltage Correlation P2135 Throttle Position (TP) Sensor 1/2 Correlation Incorrect Voltage
P2138 Accelerator Pedal Position (APP) Sensor 1/2 (Throttle Position Sensor D / E) Incorrect Voltage P2138 Accelerator pedal (APP) Sensor 1/2 (throttle position sensor D / E) Incorrect voltage
Correlation Correlation
P2176 Throttle Actuator Control System Idle Position Not Learned P2176 Throttle Actuators Idle Control Systems Not Learned
P2195 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Signal Stuck Lean P2195 combustible mixture (A / F) Sensor (sensor 1) Signal Stuck Lean
P2197 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) Signal Stuck Lean P2197 Fuel Mixture Front (A / F) Sensor (Bank 2, Sensor 1) Stuck Lean Signal
P2227 Barometric Pressure (BARO) Sensor Circuit Range / Performance Problem Atmospheric Pressure P2227 (BARO) Sensor Circuit Range / Performance Problems
P2228 Barometric Pressure (BARO) Sensor Circuit Low Voltage Atmospheric Pressure P2228 (BARO) Low Voltage Sensor Circuit
P2229 Barometric Pressure (BARO) Sensor Circuit High Voltage Atmospheric Pressure P2229 (BARO) High Voltage Sensor Circuit
P2237 Rear Air / Fuel Ratio (A / F) Sensor (Bank 1, Sensor 1) IP Line High Voltage P2237 Rear combustible mixture (A / F) Sensor (Bank 1, Sensor 1) IP high voltage lines
P2238 Air / Fuel Ratio (A / F) Sensor (Sensor 1) AFS + Line Low Voltage P2238 combustible mixture (A / F) sensor (sensor 1) + AFL low voltage
P2238 Rear Air / Fuel Ratio (A / F) Sensor (Bank 1, Sensor 1) IP Line Low Voltage P2238 Rear combustible mixture (A / F) Sensor (Bank 1, Sensor 1) IP low voltage lines
P2240 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) IP Line High Voltage P2240 Front Fuel / A / F Sensor (Bank 2, Sensor 1) High Voltage IP Lines
P2241 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) IP Line Low Voltage P2241 Front Fuel / A / F Sensor (Bank 2, Sensor 1) Low Voltage IP Lines
P2243 Rear Air / Fuel Ratio (A / F) Sensor (Bank 1, Sensor 1) VCENT Line High Voltage P2243 Rear combustible mixture (A / F) Sensor (Bank 1, Sensor 1) VCENT high voltage line
P2245 Rear Air / Fuel Ratio (A / F) Sensor (Bank 1, Sensor 1) VCENT Line Low Voltage P2245 Rear combustible mixture (A / F) Sensor (Bank 1, Sensor 1) VCENT low voltage line
P2247 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) VCENT Line High Voltage P2247 Front fuel / A / F Sensor (Bank 2, Sensor 1) VCENT high voltage line
P2249 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) VCENT Line Low Voltage P2249 Front fuel / A / F Sensor (Bank 2, Sensor 1) VCENT low voltage line
P2251 Rear Air / Fuel Ratio (A / F) Sensor (Bank 1, Sensor 1) VS Line High Voltage P2251 Rear combustible mixture (A / F) Sensor (Bank 1, Sensor 1) C. High voltage lines
P2252 Air / Fuel Ratio (A / F) Sensor (Sensor 1) AFS-Line Low Voltage P2252 combustible mixture (A / F) sensor (sensor 1) AFS-line low voltage
P2254 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) VS Line High Voltage P2254 Front Fuel / A / F Sensor (Bank 2, Sensor 1) C. High Voltage Line
P2255 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) VS Line Low Voltage P2255 Front Fuel / A / F Sensor (Bank 2, Sensor 1) C. Low Voltage Line
P2279 Intake Air System Leak P2279 Leak Intake System
P2413 Exhaust Gas Recirculation (EGR) System Range / Performance Problem P2413 Exhaust Gas Recirculation (EGR) System Range / Performance Problems
P2422 Evaporative Emission (EVAP) System Vent Shut Valve Close Malfunction P2422 Evaporative Emissions (Evaporations) Vent System Jester Valve Fault Close
P2552 Throttle Actuator Control Module Relay Malfunction P2552 Drive Module Traction Relay Malfunction
P2627 Rear Air / Fuel Ratio (A / F) Sensor (Bank 1, Sensor 1) LABEL Circuit Low Voltage P2627 Rear combustible mixture (A / F) Sensor (Bank 1, Sensor 1) LABEL low voltage circuit
P2628 Rear Air / Fuel Ratio (A / F) Sensor (Bank 1, Sensor 1) LABEL Circuit High Voltage P2628 Rear combustible mixture (A / F) Sensor (Bank 1, Sensor 1) LABEL high voltage circuit
P2630 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) LABEL Circuit Low Voltage P2630 Front Fuel / A / F Sensor (Bank 2, Sensor 1) LABEL Low Voltage Circuit
P2631 Front Air / Fuel Ratio (A / F) Sensor (Bank 2, Sensor 1) LABEL Circuit High Voltage P2631 Fuel Mixture Front (A / F) Sensor (Bank 2, Sensor 1) LABEL high voltage circuit
P2646 VTEC Oil Pressure Switch Circuit Low Voltage P2646 VTEC Oil Pressure Switch Circuit Low Voltage
P2647 VTEC Oil Pressure Switch Circuit High Voltage P2647 VTEC Oil Pressure Switch Circuit High Voltage
P2648 VTEC Solenoid Valve Circuit Low Voltage P2648 VTEC Solenoid Valve Low Voltage Circuit
P2649 VTEC Solenoid Valve Circuit High Voltage P2649 VTEC Solenoid Valve High Voltage Circuit
P2769 Short in Torque Converter Clutch Solenoid Valve Circuit P2769 Short to Torque Converter Clutch Solenoid Valve Circuit
P2770 Open in Torque Converter Clutch Solenoid Valve Circuit P2770 Open in torque converter clutch solenoid valve circuit
P2A00 Air / Fuel Ratio (A / F) Sensor (Sensor 1) Range / Performance Problem P2A00 combustible mixture (A / F) sensor (Sensor 1) Range / Performance problems
P2A03 Front A / F Sensor Circuit (Bank 2, Sensor 1) Circuit Range / Performance Problem P2A03 Front / F Sensor Circuit (Bank 2, Sensor 1) Circuit Range / Performance Problem
U0073 FCAN Malfunction (Bus-off) Fault FCAN U0073 (Bus-off)
U0107 Lost Communication With Throttle Actuator Control Module U0107 Lost Throttle Communication Drive Control Module
U0121 FCAN Malfunction (TCS-PCM) U0121 FCAN Malfunction (TCS-PCM)
