Audi A3 1996-2001 Error codes
Error codes and their interpretation of the Audi A3 from 1996-2001 AEH engines
Air conditioning system
|
0241 |
voltage power supply |
|
0258 |
Sensor provisions motor temperature damper |
|
0259 |
Sensor motor position central dampers |
|
025A |
Sensor motor position dampers lower cabin / heated windows |
|
025V |
Motor damper lower cabin / heated windows |
|
0250 |
Sensor motor position shutter overlap |
|
0271 |
Signal speeds movements |
|
030B |
Sensor temperatures outdoor of air |
|
0311 |
Sensor temperatures remote control of management |
|
0318 |
Push button switch air conditioner |
|
031C |
Sensor temperatures fan |
|
031D |
Photosensor of the sun radiation |
|
04B6 |
The gap of time Ignition Switched off |
|
04F7 |
Motor temperature damper |
|
04F8 |
Motor central damper |
|
04F9 |
Fan fresh of air |
|
04FA |
Servo motor shutoff air pressure |
|
0510 |
Medium temperature sensor air flow |
|
0511 |
Sensor temperatures flow at the bottom of the cabin |
|
FFFF |
Electronic control Numbers, the node |
|
FFFF |
No defects saved |
Alarm - Interior Control
|
0561 |
Left ultrasonic anti-theft alarm sensor |
|
0562 |
Right ultrasonic anti-theft alarm sensor |
|
0563 |
Sensor control inside the car |
|
0564 |
Triggering of anti-theft alarm system from the rear left |
|
0565 |
Triggering the anti-theft alarm system from the rear right |
|
0566 |
Triggering of anti-theft alarm system ahead left |
|
0567 |
Triggering of anti-theft alarm system ahead right |
|
FFFF |
Control , Digit knot |
Airbag system
|
01EEE |
Power supply |
|
01BF |
Power supply |
|
0214 |
Power supply |
|
024C |
Ignition circuit 1 driver's front airbag |
|
024D |
Ignition Circuit 1 Front Airbag from the side front passenger |
|
0253 |
Data collisions saved |
|
028E |
Chain tensioner ignitor seat belt driver's side ahead |
|
028F |
Chain tensioner ignitor seat belt on the passenger side in front |
|
029С |
Power supply |
|
03В1 |
Sensor collision, collision |
|
03С1 |
Lock switch , side passenger |
|
0408 |
Lock switch , side passenger |
|
0409 |
Lock switch , side passenger |
|
04ВВ |
Ignition circuit device tensioner . seat belt driver's side rear |
|
04BC |
Chain tensioner ignitor belt beop . on the passenger side behind |
|
04BE |
Block of management pillow security |
|
04С1 |
Contour: side airbag in front of the driver |
|
04С2 |
Contour: side airbag in front of the passenger |
|
04С5 |
Side impact sensor, driver's side, front |
|
04С6 |
Side Impact Sensor from the side of the seat next to the driver, in front |
|
04С7 |
The signal to open the centralized locking device |
|
04SA |
Side Airbag Passenger Side |
|
04СВ |
Side Airbag Passenger Side |
|
04SS |
Passenger Airbag Deactivation Switch |
|
0500 |
Airbag Passenger Driver Side |
|
0529 |
Block of management pillow security |
|
0556 |
Opening by signal collisions |
|
062A |
Passenger Airbag - Signal deactivation lamp |
|
0631 |
Lock switch , side passenger |
|
0632 |
Lock switch , side passenger |
|
0634 |
Contour: driver airbag |
|
0635 |
Contour: passenger airbag |
|
063E |
Power supply |
|
0664 |
Gas generator detonator for accidents Foot belt tensioner behind the driver |
|
0665 |
Detonator gas generator for accidents Foot belt tensioner driver's neighbor |
|
0678 |
Signal collisions |
|
067B |
Pretensioner belt security |
|
0A2B |
Power supply |
|
0A2C |
Power supply |
|
1523 |
Signal collisions |
|
1642 |
Block of management pillow security |
|
1750 |
Voltage batteries |
|
1751 |
Voltage batteries |
|
1752 |
Voltage batteries |
|
1757 |
Voltage batteries |
