MAN (FFR) Error codes

Code (SPN)

Description

Cause, check and response system

00038

Reserve, fuel level in tank 2.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 3. Unacceptable; 5. Short to ground; 6. Closure to Ubat .; 10. Breakage. Pin assignment A302: R1 / 14.

00070

Signal "Parking brake".

Priority 2: Fault requiring elimination at a service center. Type of fault: 8. Wrong signal.

00096

Reserve, fuel level in tank 1.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 3. Unacceptable; 5. Short to ground; 6. Closure to Ubat .; 10. Breakage. Pin assignment A302: R1 / 13.

00098

Engine oil level.

00100

The signal "oil pressure in the engine."

Priority 4: No indication, no effect on serviceability. Type of fault: 8. Wrong signal.

00102

Signal "charge air pressure".

The warning light on the dashboard always glows red when driving and stopping. Instead of a real pressure signal, a substitute signal is simulated. An insufficient amount of air enters the engine, as a result of which power is significantly reduced. The sensor is faulty, the wiring is broken, the contacts are not tight, the intercooler (intercooler) is clogged or the charge air system is not tight.

00110

Engine Coolant Temperature Signal.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. Wrong signal.

00111

The signal "engine coolant level".

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure to U bat; 10. Breakage. Pin assignment A302:R 1/13.

00158

ZBR 2 power supply when the ignition is on (ignition lock terminal 15).

Priority 2: Fault requiring elimination at a service center. Pin assignment A302: ZE17.

00159

Reserve, level, gas pressure in the tank.

Priority 2: Fault requiring elimination at a service center. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure on U bat. Pin assignment A302: X / 1.

00168

The power supply voltageZBR 2, constant plus from the batteries is missing (terminal 30-0 U bat.).

Priority 1: The engine must be stopped. Type of fault: 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 18.

00171

Outdoor temperature.

00175

Engine oil temperature.

00190

Engine speed

The warning light on the dashboard always glows red when driving and stopping. The engine cannot be started or the engine may stall spontaneously. Recording and collecting data on the crankshaft and camshaft rotation speed signal does not function.

00513

Engine torque

00520

Signal "Deceleration of braking-retarder".

Priority 4: No indication, no effect on serviceability. Type of fault: 8. Wrong signal.

00597

Signal "Brake ABS, ASR, EBS"

Priority 2: Fault requiring elimination at a service center. Type of fault: 8. Wrong signal.

00639

T - CAN data bus Higt , serial communication.

Priority 1: The engine must be stopped. Type of fault: 4. No signal. Pin assignment A302: M / 1.

00639

T - CAN data bus Lowserial communication.

Priority 1: The engine must be stopped. Type of fault: 4. No signal. Distribution of contacts A302: M / 7.

00767

Transmission R.

Priority 2: Fault requiring elimination at a service center. Type of fault: 5. Short to ground. Pin assignment A302: M / 6.

01007

The function of replacing the brake signal.

01031

Parking light replacement function.

01086

Residual pressure in the 3-circuit electric pneumatic system ( ECAM ).

Priority 1: Motor stop required or Priority 2: Fault requiring elimination at a service center. Type of fault: 1. Too high; 2. Too low; 4. No signal; 6. Closure on U bat. Pin assignment A302: R1/8.

01087

Residual pressure in 1 circuit of the electric pneumatic system ( ECAM ).

Priority 1: The engine must be stopped. Type of fault: 1. Too high; 2. Too low; 4. No signal; 6. Closure on U bat. Pin assignment A302: R 1/11.

01088

Residual pressure in the 2-circuit electric pneumatic system ( ECAM ).

Priority 1: The engine must be stopped. Type of fault: 1. Too high; 2. Too low; 4. No signal; 6. Closure on U bat. Pin assignment A302: R 1/9.

01089

Residual pressure in the 4-circuit electric pneumatic system ( ECAM ).

Priority 1: The engine must be stopped. Type of fault: 1. Too high; 2. Too low; 4. No signal; 6. Closure on U bat. Pin assignment A302: M / 2.

01235

I - CAN data bus Higt , serial communication.

Priority 1: The engine must be stopped. Type of fault: 4. No signal. Pin assignment A302: R2 / 9.

01235

I - CAN data bus Low serial communication.

Priority 1: The engine must be stopped. Type of fault: 4. No signal. Pin assignment A302: R2 / 10.

01376

The power supply voltageZBR 2, constant plus from the batteries is missing (terminal 30-1 U bat.).

Priority 1: The engine must be stopped. Type of fault: 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 13.

01624

Car speed

01667

Deceleration brake signal (waiting time has expired).

Priority 2: Fault requiring elimination at a service center. Type of fault: 8. Wrong signal.

02987

The chassis number in the tachograph or the ZBR 2parameters do not fit the car.

Priority 1: The engine must be stopped. Type of malfunction: 3.Unacceptable.

03000

ZBR 2 system , emergency shutdown information.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground. Pin assignment A302: F1 / 12.

03001

ZBR2 system, computer wake up.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground. Pinout A302: F1 / 11.

03102

Terminal 30-1 connected.

Priority 1: The engine must be stopped. Type of fault: 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 9.

03103

ZBR 2 supply voltage , analogue mass.

Pin assignment A302: M / 16.

03104

ZBR 2 supply voltage , analogue mass.

Pin assignment A302: R1 / 15.

03107

Power supply ZBR 2, ignition on (relay terminal 15).

Priority 2: Fault requiring elimination at a service center. Type of fault: 5. Short to ground; 10. Breakage. Pinout A302: F 2/12.

03108

Power supply ZBR 2 batteries power switch.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 10. Breakage. Pin assignment A302: F2/18.

03111

ZBR 2 supply voltage , starter switch (terminal 50).

Priority 1: The engine must be stopped. Priority 2: Fault requiring elimination at a service center. Priority 3: Display during stop. Priority 4: No indication, no effect on serviceability.Priority 5: Indication during stop and while driving. Pin assignment A302: ZE / 5.

03201

Pressure drop on the engine air filter.

Priority 5: Indication during stop and while driving. Type of fault: 2. Too low; 5. Short to ground; 6. Closure on U bat. Pin assignment A302: X / 3.

03300

Generator, terminal W.

Priority 2: Fault requiring elimination at a service center. Type of malfunction: 3. Unacceptable. Distribution of contacts A302: M / 14.

03301

Generator, terminal L.

Priority 2: Fault requiring elimination at a service center. Type of fault: 4. No signal. Pin assignment A302: M / 4.

03302

Generator, terminal B +.

Priority 3: Display during stop. Type of fault: 5. Short to ground; 6. Closure to Ubat .; 10. Breakage. Distribution of contacts A302: M / 8.

03303

Signal D + (engine running).

Priority 2: Fault requiring elimination at a service center. Type of fault: 5. Short to ground; 6. Closure on U bat. Pin assignment A302: F 2/17.

03335

Power supply (no data available).

Priority 4: No indication, no effect on serviceability. Fault type: 0. Fault is absent or the control unit is faulty.

03400

Solenoid valve preheating.

Priority 3: Display during stop. Type of fault: 5. Short to ground; 6. Closure to Ubat .; 10. Breakage. The layout of contacts A302: M / 13.

03401

Preheating relay.

Priority 3: Display during stop. Type of fault: 5. Short to ground; 6. Closure to Ubat .; 10. Breakage. Pin assignments A302: ZE / 8.

03402

The glow plug current is preheated.

Priority 3: Display during stop. Type of fault: 10. Open. Pin assignment A302: ZE / 19.

03403

The glow plug current is preheated.

Priority 3: Display during stop. Type of fault: 2. Too low; 3. Unacceptable; 10. Breakage. Pin assignment A302: ZE / 20.

03500

Fault ABS trailer (ABS, ASR, EBS).

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty. Pin assignment A302: X / 2.

03501

ABS trailer, current consumption.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 5. Short to ground; 6. Closure to U baht .; 10.Breakage. Pin assignment A302: R2 / 14.

03502

Brake light.

Priority 2: Fault requiring elimination at a service center. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure to U baht .; 10. Breakage. Pin assignment A302: R2 / 4.

03503

Trailer braking signal.

Priority 2: Fault requiring elimination at a service center. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure to U baht .; 10. Breakage. Pin assignment A302: R2 / 5.

03568

The retarder is on.

Fault type: 0. Fault is absent or the control unit is faulty.

03569

The engine brake is on.

Fault type: 0. Fault is absent or the control unit is faulty.

03570

Service brakes on.

Fault type: 0. Fault is missing or the control unit is faulty.

03600

The fluid level in the clutch drive.

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure to U bat; 10. Breakage. Pin assignment A302:R 1/2.

03602

Relay lights reversing.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: F 2/13.

03603

Turn on the Kongsberg heating system.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Distribution of contacts A302: M / 18.

03625

Downshift.

Priority 2: Fault requiring elimination at a service center. Fault type: 6. Closure at Ubat. Pin assignment A302: X / 4.

03800

Front axle level (air suspension ECAS ).

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 4. No signal; 5.Short to ground. Pinout A302: R2 / 17.

03903

Fuel temperature in tank 1.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low. Pin assignment A302: R 1/10.

04000

Headlight Switch

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pinout A302: F 1/17.

04001

Low beam, left side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: BL / 6.

04002

Middle light, right side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: BR / 2.

04003

Left headlight, height adjustment.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 3. Unacceptable;4. No signal; 8. The signal is incorrect; 9. Faulty component.Pin assignment A302: BL / 3.

04004

Right headlight, height adjustment.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 3. Unacceptable;4. No signal; 8. The signal is incorrect; 9. Faulty component.Pin assignment A302: BR / 6.

04005

Turn indicator on the tractor, left rear.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure toU baht .; 10. Breakage. Pin assignment A302: R2 / 1.

04006

Turn indicator on the tractor, right rear.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure toU baht .; 10. Breakage. Pinout A302: R2 / 13.

04007

Turn indicator on the tractor, left front or side.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure toU baht .; 10. Breakage. Pin assignment A302: BL / 4.

04008

Turn indicator on the tractor, right front or side.

Priority 5: Indication during stop and while driving. Pin assignment A302: BR / 3.

04009

Turn indicator switch, Hall sensor (on the steering wheel on the left).

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure on Ubat .; Pin assignment A302: F1 / 3.

04010

Turn indicator switch, Hall sensor (on the steering wheel to the right).

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure on Ubat .; Pin assignment A302: F1 / 6.

04011

Switch flashing light on the left.

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure to U bat; 10. Breakage. Pinout A302: F 1/15.

04012

Flashing light switch on the right.

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure to U bat; 10. Breakage. Pin assignment A302:F 1/16.

04013

Alarm, warning lamp.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: F 2/16.

04014

Alarm, switch.

Priority 2: Fault requiring elimination at a service center. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage. Pin assignment A302: F 1/1.

04015

Turn indicator on trailer, left.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure toU baht .; 10. Breakage. Pin assignment A302: R2 / 3.

04016

Direction indicator on trailer, right.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure toU baht .; 10. Breakage. Pin assignment A302: R2 / 2.

04017

High beam, left side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: BL / 5.

04018

High beam, right side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: BR / 1.

04019

Main light, key switch.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: F 1/13.

04020

Intermittent headlights, a key switch.

04021

Extra high beam, left side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: BL / 1.

04022

Extra high beam, right side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: BR / 4.

04023

Extra high beam on the roof, relay.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage.Pin assignment A302: F 2/14.

04024

Rear fog lights on the tractor.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure toU baht .; Pin assignment A302: R 2/16.

04025

Rear fog lights on the trailer.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Closure toU baht .; Pin assignment A302: R 2/15.

04026

Fog lights, right side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage. Pin assignment A302: BR / 5.

04027

Fog lights, left side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; 10. Breakage. Pin assignment A302: BL / 2.

04028

Indicator lamp fog lights, unlock the inclusion.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Closure to U baht .; Pin assignment A302: X / 12.

04029

Additional fog lamp, relay.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/18.

04030

Parking lights on the tractor, right side.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 1.

04031

Parking lights on the tractor, left side.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 7.

04032

Parking lights, right side.

Priority 5: Indication during stop and while driving. Type of malfunction: 3. Unacceptable. Pin assignment A302: ZE / 10.

04033

Parking lights, left side.

Priority 5: Indication during stop and while driving. Type of malfunction: 3. Unacceptable. Pin assignment A302: ZE / 14.

04034

Side marker lights, right side.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pinout A302: R2 / 7.

04035

Side marker lights, left side.

Priority 5: Indication during stop and while driving. Type of fault: 1. Too high; 2. Too low; 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: R2 / 6.

04036

Parking lights for the trailer, right side.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 3.

04037

Lanterns trailer side light, left side.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 1. Too high; 2. Too low; 10. Breakage. Pin assignments A302: ZE / 2.

04038

Parking light relay.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignments A302: ZE / 4.

04039

Parking light switch.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 1/14.

04040

Winter mode, relay.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/18.

04042

Check the lighting.

Priority 6: An indication of the critical state for safety. 0. Fault absent or faulty control unit.

04043

Check lighting, lock.

Priority 4: No indication, no effect on serviceability. Fault type: 0. Fault is absent or the control unit is faulty.

04044

Check lighting, unlocking.

Priority 4: No indication, no effect on serviceability. Fault type: 0. Fault is absent or the control unit is faulty.

04045

Turn signaling system on both sides, switching on.

Priority 5: Indication during stop and while driving. Type of malfunction: 3. Unacceptable.

04046

Identification of the calibration system for the installation of the angle of the headlights.

Priority 4: No indication, no effect on serviceability. Fault type: 0. Fault is absent or the control unit is faulty.

04100

Near winter light, right side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: BR / 2.

04101

Near winter light, left side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: BL / 6.

04102

Far winter light, right side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: BR / 1.

04103

Far winter light, left side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: BL / 5.

04104

Rear winter parking lights, right side.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 1.

04105

Rear winter parking lights, left side.

Priority 5: Indication during stop and while driving. Fault type: 0. Fault is absent or the control unit is faulty; 1. Too high; 2. Too low; 10. Breakage. Pin assignment A302: ZE / 7.

04109

Switch camouflage lights.

Priority 5: Indication during stop and while driving. Pin assignment A302: F1 / 2.

04113

Parking light, right side, relay.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: X / 17.

04200

Interior lighting and footrest lighting, right side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/5.

04201

Interior lighting and footrest lighting, left side.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/4.

04300

Washer fluid level sensor.

Priority 5: Indication during stop and while driving. Type of fault: 2. Too low; 6. Closure on U bat. Pin assignment A302: F 1/7.

04301

Washer fluid pump.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/15.

04302

Wiper, intermittent switch.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; Pin assignment A302: F1 / 5.

04303

The wiper which sets the generator of the switch of the discontinuous mode.

Priority 2: Fault requiring elimination at a service center. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: X / 18.

04304

Windscreen washer, rocker switch.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; Pin assignment A302: F1 / 4.

04305

Wiper, rain sensor signal.

Priority 3: Display during stop. Pin assignment A302: F1 / 18.

04306

Windshield washer, liquid level sensor.

Priority 5: Indication during stop and while driving. Type of fault: 2. Too low; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: R 1/5.

04307

Windshield washer, pump.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/1.

04308

Wiper motor, turns.

Priority 2: Fault requiring elimination at a service center. Pin assignment A302: F2 / 6.

04309

Wiper motor speed.

Priority 2: Fault requiring elimination at a service center. Pin assignment A302: F2 / 6.

04310

Wiper relay

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: ZE / 6.

04311

Wiper limit switch.

Priority 5: Indication during stop and while driving. Type of malfunction: 3. Unacceptable; 4. No signal. Pin assignment A302: F1 / 10.

04312

Wiper switch.

Priority 2: Fault requiring elimination at a service center. Pin assignment A302: X / 15.

04400

Centralized lubrication system, the amount of lubrication in the system.

Priority 5: Indication during stop and while driving. Type of fault: 2. Too low; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/8.

04401

Centralized lubrication system, engine.

Priority 5: Indication during stop and while driving. Type of fault: 4. No signal; 5. Short to ground. Pin assignment A302: X / 16.

04402

Centralized lubrication system, pump sensor.

Priority 5: Indication during stop and while driving. Type of fault: 4. No signal; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/11.

04403

Centralized lubrication system, switch.

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure on Ubat .; Pin assignment A302: X / 6.

04500

Hydraulic steering system, oil level in 1 circuit.

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure on Ubat .; Pin assignment A302: R1 / 6.

04502

Hydraulic steering system, oil level in 2 circuit.

Priority 5: Indication during stop and while driving. Type of fault: 6. Closure on Ubat .; Pin assignment A302: R1 / 4.

04523

Hydraulic steering system, oil pressure in 1 circuit.

Priority 2: Fault requiring elimination at a service center. Type of fault: 4. No signal; 5. Short to ground. Pinout A302: X / 11.

04524

Hydraulic steering system, 2-circuit oil pressure.

Priority 2: Fault requiring elimination at a service center. Type of fault: 4. No signal; 5. Short to ground. The layout of the contacts A302: X / 10.

04600

Door contact, right.

Priority 5: Indication during stop and while driving. Pin assignment A302: F1 / 8.

04601

Door contact, left.

Priority 5: Indication during stop and while driving. Pin assignment A302: F1 / 9.

04800

Response alarm central locking.

Priority 5: Indication during stop and while driving. Type of malfunction: 3. Unacceptable. The layout of contacts A302: X / 7.

05000

Buzzer in the instrument panel.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; 10. Breakage. Pin assignment A302: F 2/9.

05001

Fault indicator lamp in the instrument panel.

Priority 5: Indication during stop and while driving. Type of fault: 5. Short to ground; 6. Short circuit on U baht .; Pin assignment A302: X / 14.

05600

Cab fixing.

Priority 1: The engine must be stopped. Fault type: 0. Fault is absent or the control unit is faulty; 6. Short circuit on U bat. Distribution of contacts A302: R 1/1.

05700

The set position of ACC (system of regulation of speed of the movement with automatic maintenance of a safe distance).

Priority 2: Fault requiring elimination at a service center. Type of fault: 5. Short to ground; 6. Short circuit on U bat. Distribution of contacts A302: F 2/2.

06000

Tachograph TCO 1, failure when receiving or transmitting messages.

Priority 2: Fault requiring elimination at a service center. Type of fault: 8. The signal is incorrect.

06001

ACC (speed control system with automatic maintenance of a safe distance), failure when receiving or sending messages.

Priority 5: Indication during stop and while driving. Type of fault: 8. The signal is incorrect.

06002

Date and time, failure when receiving or transmitting messages.

Priority 2: Fault requiring elimination at a service center. Type of fault: 8. The signal is incorrect.

06003

Vehicle speed control, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06004

Dashboard failure when receiving or transmitting messages.

Priority 2: Fault requiring elimination at a service center. Type of fault: 8. The signal is incorrect.

06005

Post EBS 1 system EBS (brake system with electronic control), rejection when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06006

Post ECAS 1 System ECAS (air suspension with electronically controlled), failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06008

Message EEC 1 (electronic motor controller) of the FFR system (car computer), failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06009

Message ERC _ RE auxiliary retarder, failure when receiving or sending a message.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06010

ERC _ RD message of the primary retarder, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06011

Engine oil pressure, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06012

Coolant temperature, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06013

Environmental parameters, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06016

Post EBS 3 system EBS (brake system with electronic control), rejection when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06017

Post EBS 4 system EBS (brake system with electronic control), rejection when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06018

Motor shaft speed signal, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06020

Message ETC 2 systems FFR , failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06021

Message ETC 3 of the FFR system , failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06022

Signal on fuel consumption since the last reset, failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 4. No signal.

06023

Signal about fuel consumption in liters per hour, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06024

Information about the pressure of the injected air, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06025

Message TC 1_ FT of the FFR system with an automatic transmission, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06026

Message ACC 1 of the signal display ACC , failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06027

The aux _ stat _ ZBR _1 signal is not transmitted over the T - CAN data channel as 1 message, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability.

06028

The aux _ stat _ ZBR _1 signal is not transmitted via the I - CAN data channel as 1 message, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability.

06029

The signal in the data channel I - CAN level indicator in the tank washer fluid, failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability.

06030

Message engine brake the ERC 1_ the RX of the FFR , failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06032

The aux _ stat _ ZBR _2 signal is not transmitted over the I - CAN data channel as a 2 message, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability.

06033

The aux _ stat _ ZBR _3 signal is not transmitted via the I - CAN data channel as a 3 message, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability.

06034

The backup signal Aux _ stat _ ZBR _4 is not transmitted over the I - CAN data channel as 4 messages, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability.

06035

Signal "Vehicle power" in the CAN data channel , voltage at terminals 30 and 15 from the EDC via FFR , failure during reception or transmission of messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06036

Liquid level signal in the auxiliary retarder, refusal to receive or transmit messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06037

A signal about the level of the fluid in the main retarder, a refusal to receive or transmit messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06038

Message EEC 2 2 electronic engine control system, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06039

A signal about a level of a liquid in a transmission, refusal at reception or at transfer of messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06040

Rear axle load signal ( EBS system ), failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06041

A signal to load a car ( ECAS system ), a failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06042

A signal about the configuration of the engine, failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06043

The message " SPN Response (request for MAN data )" via the I - CAN data channel , failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06044

The message " SPN Response (request for MAN data )" via the I - CAN data channel , failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability.

06045

ECAM 1 message on data channel T - CAN , signal of remaining pressure, failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability.

06046

Message from the WSK system (hydrotransformer clutch), failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06047

The VDC 1 message is not accepted due to a malfunction of the T - CAN data channel , failure during reception or transmission of messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06048

ETC 2 message via I - CAN data channel , failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability.

06050

DM 1 message from ZBR 2 via I - CAN data channel , failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability.

06051

DM 1 message of fault memory and OBDU memory (on-board diagnostics device), failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability.

06052

Message on the chassis number via the I - CAN data channel , failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06053

Message from KSM 2 (control device for external data exchange) via data channel T - CAN , failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06054

Post the ECAS the AS S1_A (air suspension with electronically controlled), failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06055

Message ECAS AS С1_ B (electronically controlled air suspension), failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06056

Message ECAS AS С1_ B (electronically controlled air suspension), failure when receiving or transmitting messages.

06057

Message on the chassis number via the I - CAN data channel , failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06058

Aux _ Stat Inst 2 signal via I - CAN data channel, there are no switching messages in the data channel, failure during reception or transmission of messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06059

ESP message failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06060

Post ECAS AS C3 (electronically controlled air suspension), failure when receiving or transmitting messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06061

The message about the weight of the car from the system ECAS (air suspension with electronic control), failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06062

The message about the weight of the car from the system EBS (brake system with electronic control), failure when receiving or sending messages.

Priority 4: No indication, no effect on serviceability. Type of fault: 8. The signal is incorrect.

06202

Aux _ stat _ ZBR 2 message on the I - CAN data channel (manufacturer’s reserve for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability.

06203

Aux _ stat _ ZBR 3 message on the I - CAN data channel (manufacturer’s reserve for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability.

06204

Modified message ETC 2 via data channel I - CAN (manufacturer's reserve for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability.

06205

Message from the dashboard via the I - CAN data channel (manufacturer's reserve for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability.

06206

ECAM 1 message over T - CAN data channel (manufacturer's reserve for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability.

06207

ECAM 1 message over I - CAN data channel (manufacturer's reserve for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability.

06208

Message DM 1 ZBR 2 (manufacturer's reserve for ZBR or ZBRO ).

Priority 5: Indication during stop and while driving.

06209

Post DM 1 OBDU data channel I - CAN (manufacturer reserve for ZBR or ZBRO ).

Priority 5: Indication during stop and while driving.

06250

There is no CAN data channel message buffer (manufacturer's backup for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability. Type of fault: 4. No signal.

06251

Messages in the CAN data channel are not processed (manufacturer's reserve for ZBR or ZBRO ).

Priority 4: No indication, no effect on serviceability. Type of fault: 4. No signal.

06280

Error checking ROM (program code) (manufacturer's reserve for ZBR or ZBRO ).

Priority 2: Fault requiring elimination at a service center. Type of malfunction: 3. Unacceptable.

06281

Error checking ROM (parameter EOL (factory programming)) (manufacturer's reserve for ZBR or ZBRO ).

Priority 2: Fault requiring elimination at a service center. Type of malfunction: 3. Unacceptable.

06302

K-cable for KWP 2000 (PC Diagnostic Protocol), serial communication.

Priority 2: Fault requiring elimination at a service center. Pin assignment A302: M / 10.

06303

T - CAN Masse , serial communication.

Distribution of contacts A302: M / 9.

06304

T - CAN data channel temporary failure signal , serial communication.

Priority 4: No indication, no effect on serviceability. Type of fault: 4. No signal.

06305

I - CAN data channel temporary failure signal , serial communication.

Priority 4: No indication, no effect on serviceability. Type of fault: 4. No signal.

08010

Reporting a pressure drop below the allowable level in ECAM (electronically controlled air suspension).

Priority 1: Motor stop required or Priority 2: Fault requiring elimination at a service center. Type of fault: 2. Too low.

08104

Residual pressure in the 5 circuit (input circuit) in the ECAM system (electronically controlled air suspension).

Priority 1: The engine must be stopped. Type of fault: 1. Too high; 2. Too low; 4. No signal; 6. Closure on U bat. The layout of contacts A302: M / 15.
